  • Piezo Buzzer HP2312XW
Piezo Buzzer HP2312XW

Piezo Buzzer HP2312XW

  • Product description: Piezo Buzzer HP2312XW -Datasheet-Wire type ,Internal Circuitry , Dia 23x12mm Worked with 12V DC, Output3.5~ 4.5K Hz 85dB at 10cm​
  • INQUIRY

Piezo Buzzer HP2312XW

Buzzer Datasheet:
Wire type ,Internal Circuitry , Dia 23x12mm Worked with 12V DC, Output3.5~ 4.5K Hz 85dB at 10cm

Type

UNIT

HP2312AXW

HP2312BXW

*Min. Sound Output at10cm

dB

85

90

Rated Voltage

VDC

12

12

Operating Voltage

VDC

3~20

3~20

Resonant Frequency

Hz

3500±500

4500±500

*Max. Current Consumption

mA

8

8

Tone Nature


Continuous

Operating Temperature

°C

-20~+70

Storage Temperature

°C

-30~+80

Weight

g

8



Value applying at rated voltag

DIMENSIONS     Unit:mm     Tolerance:±0.5
